TANGENTIAL FAN

SKU: VT270D

You must to view prices.

Usually ships in 1 to 2 daysDetails

Double aluminum turbine - Ø 60 mm - Length 270 mm. Centrally mounted motor. Voltage 220/240 V - 50/60 Hz. Power 40 W - Speed 1000 rpm. Airflow 300 m³/h. Operating temperature -10 °C to +60 °C. Terminals 6.35 x 0.8. Two 272 x 35 mm air outlets. Dimensions: Length 645 mm - Width 112 mm - Height 94 mm.

Technical Specifications

RPM (50 Hz)	1000
A_0230900_DEBITMAXI	300
Turbine length	270 mm
Ø turbine	60 mm
Engine position	Center
Single or double	Double
Power supply	230 V
Power (W)	40 W
Connections	6,35 mm lugs
Length	645 mm
Width	112 mm
Height	94 mm
Minimum temperature (use)	-10 °C
Max. temperature (use)	60 °C
Material	Aluminium
