TANGENTIAL FAN

SKU: VT18F3D

You must to view prices.

Usually ships in 1 to 2 daysDetails

Aluminum turbine – Ø 60 mm – Length 180 mm polska-ed.com. Right-hand motor. Voltage 220/240 V – 50/60 Hz. Power 28 W – Speed 1500 rpm. Airflow 140 m³/h. Operating temperature -10 °C to +60 °C. Cable length 1.20 m. Outlet 183 x 35 mm. Dimensions: Length 245 mm – Width 100 mm – Height 100 mm.

Technical Specifications

RPM (50 Hz)	1500
A_0230900_DEBITMAXI	140
Turbine length	180 mm
Ø turbine	60 mm
Engine position	Right
Single or double	Simple
Power supply	230 V
Power (W)	28 W
Connections	Cable
Wire/cable length	1,20 m
Length	245 mm
Width	100 mm
Height	100 mm
Minimum temperature (use)	-10 °C
Max. temperature (use)	60 °C
Material	Aluminium
Compatibility	PANIMATIC
