TANGENTIAL FAN

VT180D
You must to view prices.
Usually ships within 0 daysDetails
Double aluminum turbine - Ø 60 mm - Length 180 mm. Centrally mounted motor. Voltage 220/240 V - 50/60 Hz. Power 38 W - Speed 1300 rpm. Airflow 235 m³/h. Operating temperature -10 °C to +60 °C. Terminals 6.35 x 0.8. Two 183 x 35 mm air outlets. Dimensions: Length 465 mm - Width 112 mm - Height 94 mm.
  • Technical Specifications
RPM (50 Hz) 1300
Max. flow (m³/h) 235
Turbine length 180
Ø turbine 60
Engine position Center
Single or double Double
Power supply 230 V
Power (W) 38
Connections 6,35 mm lugs
Length 465
Width 112
Height 94
Minimum temperature (use) -10
Max. temperature (use) 60
Material Aluminium
Compatibility EMMEPI
