OMRON CELL

SKU: E3JK

You must to view prices.

Usually ships in 1 to 2 daysDetails

Photoelectric cell with reversing relay output (3 A) and 2 m long cable. Power supply: 24 to 240 Vac or 24 to 240 Vdc. Dimensions: cell (50 x 50 x 17.4 mm), reflector (60 x 40 x 7 mm). Maximum detection distance: 10 m. Light On or Dark On operation. Complete kit includes cell, reflector, and side mounting bracket.

Technical Specifications

Nb of contacts	1
including inverters	1
Power supply	110 V, 230 V, 24 Vac, 24 Vdc, 28 Vac, 28 Vdc, 30 Vac, 42 Vdc, 48 Vac
Connections	Cable
Wire/cable length	2
Maximum intensity	3
Detector type	Photocell
Max. detection distance	10
Width	40
Height	60
Internal diameter	7
Component manufacturer	OMRON
