EWHS2840/W RH% PROBE 4...20 MA

SKU: EWHS2840/W

You must to view prices.

Usually ships in 1 to 2 daysDetails

80 x 80 x 50 mm polycarbonate housing with IP65 protection, including sensor protection. Humidity range 0-100% RH, accuracy +/- 3%, operating temperature -40-60°C. Stable 3 mA signal in case of failure, 9-28 Vdc power supply. Maximum load resistance 150 ohms. Screw connector, 2 wires. Replaces the older EWHS284 and EWHS18 models. Digital sensor with integrated calibration. Sensor cap and cable gland in a low position to prevent liquid ingress.

Technical Specifications

Type of probe	4-20mA, Humidity, Room sensor
Probe features	Boitier en polycarbonate 808050mm
Minimum % RH	0
Maximum % RH	100
Power supply	12 Vdc, 24 Vdc
Nb of threads	2
Minimum temperature (use)	-40 °C
Max. temperature (use)	60 °C
IP protection	65
Type of equipment	Fermentation chambers
