UNIVERSAL CONTROL DEVICE

SKU: EV3411M3

You must to view prices.

Usually ships in 1 to 2 daysDetails

Ideal for various production processes thanks to its multi-sensor analog input, these control devices have up to 3 digital outputs and 1 analog output. The analog output signal can be a function of the control signal, rather than proportional to the value detected by the analog input. Control can be on/off or PID (with auto-tuning).

• Dimensions: 74 x 32 mm

• Capacitive touch buttons

• Power supply: 12-24 VAC/DC

• IP65 protection rating

**** Replaces part number EVK411M3E (thermostat/hygrostat)****

Technical Specifications

Type of probe	4-20mA, NTC, PT100, PTC, TCJ, TCK
Nb of contacts	1
including NO	1
Regulator operation	Hot OR Cold OR Humidity OR Pressure
Nb of probes	1
Delivered probes	Non
To	16A
Options	Buzzer, PID
Ergonomics	Tactile
Min. temperature	-100 °C
Max. temperature	999 °C
Power supply	12 Vac, 24 Vac
Connections	Screw terminal block
Assembly cut-out	71*29 mm
Width	75 mm
Height	32 mm
Internal diameter	59 mm
IP protection	65
Type of equipment	Convection oven, Ovens, Dishwashers
Component manufacturer	EVCO
Compatibility	ELFRAMO, MBM
