TOROIDAL TRANSFORMER 230/24 V - 50 VA

CP50/24
You must to view prices.
Usually ships in 1 to 2 daysDetails
Hooded and protected class 2 model (no grounding). Advantages of toroidal: lighter, more compact, silent operation, higher efficiency than lamellar. Connection via screw terminal block. Dimensions: height 90 mm - Ø 67 mm.
  • Technical Specifications
Connections Screw terminal block
Power (VA) 50
No. of transformer outputs 1
Transformer type Toric
Primary 230 Vac
Secondary 24 Vac
Class 2
Height 90 mm
Ø outside 67 mm
