THREE-PHASE AXIAL FANS - SPECIAL FOR PUSHER CHAMBERS

SKU: 148VK

You must to view prices.

Usually ships within 0 daysDetails

Old model 154DA
(no longer manufactured)

New model 148VK
replacement
(fits in place of) Model 148VK018102 (replaces 154DA three-phase no longer manufactured) Dimensions 172 x 150 x 38 mm. Cast aluminum motor housing, black finish. Ball bearings. Wire connection 1 m long. Nominal voltage 208-240 V - 50/60 Hz - 3 phases Power 32 W - Speed 2800 rpm Operating temperature -10 °C to +70 °C Noise level 53 dBA - Flow rate 360 m3 /h. Caution: Stronger capacitors are required to replace the old model with the new one. Evaporator with 1 fan: 2.7 MF Evaporator with 2 fans: 4.5 MF Evaporator with 3 fans: 6.6 MF Three-phase fan adaptable to panimatic* growth chambers.

Technical Specifications

RPM (50 Hz)	2800
A_0230900_DEBITMAXI	360
Power supply	3*230V
Power (W)	32
Connections	Threads
Wire/cable length	1000
Fixing center distance(s)	162
Length	172
Width	150
Internal diameter	38
Minimum temperature (use)	-10
Max. temperature (use)	70
Material	Aluminium
Form	Octagon
Type of equipment	Fermentation chambers
Component manufacturer	ETRI
Compatibility	BERKEL, CHARVET, COLGED, ELETTROBAR, PANIMATIC
