THERMOSTAT AKO 14323 230V NTC

SKU: AKO14323

You must to view prices.

Usually ships in 1 to 2 daysDetails

230V 50/60Hz, 1 relay output 16A for compressor, 1 relay output 8A configurable, 1 relay output 6A for fan, 2 digital inputs configurable (2nd probe), supplied with 2 NTC probes, mounting dimensions 71 x 29 x 61 mm

Technical Specifications

Type of probe	NTC, PTC
Nb of contacts	3
including inverters	1
including NO	2
Regulator operation	Hot OR Cold
Nb of probes	2
Delivered probes	2 NTC
Hot	16 A
Compressor	16 A
Ventilation	6 A
To	8:00 AM
Ergonomics	To keys
Min. temperature	-50 °C
Max. temperature	150 °C
Power supply	230 V
Connections	Screw terminal block
Assembly cut-out	71*29 mm
Width	80 mm
Height	38 mm
Internal diameter	60 mm
Minimum temperature (use)	-10 °C
Max. temperature (use)	50 °C
IP protection	65
Component manufacturer	AKO
