TANGENTIAL FAN

VT180
You must to view prices.
Usually ships in 1 to 2 daysDetails
Aluminum turbine - Ø 60 mm - Length 180 mm. Motor on the left. Voltage 220/240 V - 50/60 Hz. Power 28 W - Speed ​​1500 rpm. Airflow 140 m³/h. Operating temperature -10 °C to +60 °C. Terminals 6.35 x 0.8. Outlet 183 x 35 mm. Dimensions: Length 245 mm - Width 112 mm - Height 83 mm.
  • Technical Specifications
RPM (50 Hz) 1500
A_0230900_DEBITMAXI 140
Turbine length 180 mm
Ø turbine 60 mm
Engine position Left
Single or double Simple
Power supply 230 V
Power (W) 28 W
Connections 6,35 mm lugs
Length 245 mm
Width 112 mm
Height 83 mm
Minimum temperature (use) -10 °C
Max. temperature (use) 60 °C
Material Aluminium
Compatibility EMMEPI, WHIRLPOOL
