ROLLER LEVER MODEL

SKU: D4N1120

You must to view prices.

Usually ships in 1 to 2 daysDetails

1-pin thermoplastic housing and head. Contacts: 1 N/O + 1 N/C (6 A/250 VAC). IP65 protection. Operating temperature -30 to +70°C. Adjustable head in 4 directions. Housing dimensions 31 x 64 mm. Mounting: 2 holes at top, center distance 20 or 22 mm.

Technical Specifications

Nb of contacts	2
including NO	1
including NF	1
Connections	Screws
Maximum intensity	3 A
Fastening method	By body
Fixing center distance(s)	20,22
ø actuator	17 mm
Actuator width	6,80 mm
Limit switch series	D4N
Actuator type	Roller lever
Rotary	YES
Abrupt break	YES
Entries	1 entrée PG13\|5
Width	31 mm
Height	64 mm
Internal diameter	30 mm
Minimum temperature (use)	-30 °C
Max. temperature (use)	70 °C
IP protection	67
Component manufacturer	OMRON
Compatibility	TROLUX, ZANUSSI
