PROGRAMMABLE ELECTRONIC CLOCK

SKU: TS+990

You must to view prices.

Usually ships in 1 to 2 daysDetails

Backup in case of power failure via a 9V battery. Time scale: 9999 h, 99 h 59 min, 99 min 59 sec, 99 sec, and 99 hundredths of a second. 3 adjustable time settings: t1, t2, t3. Counting/decrementing function. Inputs: 2 configurable digital inputs.
Outputs: 2 relays, 8 A/250 V. Power supply: 230 Vac.
Dimensions: 71 x 29 x 59 mm.

Technical Specifications

Nb of contacts	2
including inverters	1
including NO	1
Timer type	Electronics
M/A order	Front keys
Time range	0 to 99 h
Power reserve	YES
Start function	YES
Stop function	YES
Reset function	YES
Timer modes	A, B, C, D, E, Programmable
Programming	Front keys
Power supply	230 V
Maximum intensity	8 A
Fastening method	Recessed
Assembly cut-out	71*29 mm
Width	78,60 mm
Height	37 mm
Internal diameter	59 mm
