NMB119PL COMPACT AXIAL FANS

SKU: NMB119PL

You must to view prices.

Usually ships in 1 to 2 daysDetails

Black-finished die-cast aluminum motor housing. Ball bearings protected by flanges. Operating temperature: -40°C to +70°C.

Dimensions (mm): 119 x 119 x 25 – Voltage: 230 Vac – Power: 14 W – Speed: 2300 RPM – Flow rate: 108 m³/h – Noise level: 34 dBA – Connection: 2.8 x 0.5 mm terminals

In case of stock shortage, replacement product AD1252MB

Technical Specifications

RPM (50 Hz)	2300
A_0230900_DEBITMAXI	108
Power supply	230 V
Power (W)	14 W
Connections	2,8 mm lugs
Length	119 mm
Width	119 mm
Internal diameter	25 mm
Minimum temperature (use)	-40 °C
Max. temperature (use)	70 °C
Material	Aluminium
Form	Square
Component manufacturer	NMB
