MOTOR FOR BONGARD* FAN-ASSISTED OVEN

MF12
You must to view prices.
Usually ships in 1 to 2 daysDetails
Shipping via courier (Delivery time 48/72 hours)
Special 2-speed asynchronous motor adaptable to BONGARD* fan-assisted ovens.

Technical specifications: 4/6P 2 BOB LS100L 1.5kW/0.5kW IP55 UC class F IM3001 (IMB5) FF215. Plated power supply 230/400V-50Hz 460V-60Hz Pn = 1.2. Special 24 x 42 shaft end.

Bearings with lifetime lubrication. Plastic cover. BA 24 x 42 R18.

Counter flange + Heat trap. Aluminum terminal box with 2 x M20 brass PE connectors. 2 voltages => 12 terminals

*** While supplies last ***
  • Technical Specifications
RPM (50 Hz) 1425
RPM (60 Hz) 1700
Engine mounting B14 (tapped hole flange)
Direction of rotation Reversible
Tree ø24*40 mm
Tree tip -
Key Oui
Specific application Oven turbine
Power supply 230-400 V, 400 V
Power (W) 1500 W
Connections Terminal box
Nb of threads 4
50 Hz YES
60 Hz YES
Power speed 2 (W) 500 W
Fastening method Smooth hole(s)
Fastening hole 14 mm
Nb of poles 4
No. of gears 2
Internal diameter 367 mm
Ø outside 250 mm
IP protection 55
Type of equipment Ovens, Ventilated oven
Component manufacturer HANNING
Compatibility BONGARD, LAINOX
