LEVER MODEL WITH ADJUSTABLE WHEEL

D4N112H
You must to view prices.
Usually ships in 1 to 2 daysDetails
1-pin thermoplastic housing and head. Contacts: 1 N/O + 1 N/C (6 A/250 VAC).

IP65 protection. Operating temperature -30 to +70°C. Adjustable head in 4 directions.

Housing dimensions 31 x 64 mm. Mounting: 2 holes at top, center distance 20 or 22 mm.
  • Technical Specifications
Nb of contacts 2
including NO 1
including NF 1
Connections Screws
Maximum intensity 3
Fastening method By body
Fixing center distance(s) 20,22
ø actuator 50
Actuator width 8
Limit switch series D4N
Actuator type Wheel lever
Adjustable length YES
Abrupt break YES
Entries 1 entrée PG13|5
Width 31
Height 64
Internal diameter 30
Minimum temperature (use) -30
Max. temperature (use) 70
IP protection 67
Component manufacturer OMRON
