KWH TOTALIZING METER

Model for single-phase mains supply 230V 50/60 Hz - Max. current: 80 A Direct connection - DIN rail mounting - Partial counter reset button on front panel. Simultaneous 2-line backlit LCD display (totalizer and partial meter) 5 digits + 1 decimal point Class 1 accuracy. SO pulse output on 2 terminals: 1000 Imp/kWh, from 18 to 60 Vdc. Supplied with lead-sealable terminal covers. Standard DIN rail dimensions 36.5 x 100.5 x 65 mm
