HELICOID FANS MOTOR TO GRILLE Ø 250 7 BLADES

SKU: S2E250AL0601

You must to view prices.

Usually ships in 1 to 2 daysDetails

Propeller diameter (mm): 250 - Number of blades: 7 - Voltage (V): 230 - Power (W): 120 - T: - Flow rate (m³/h): 1820 - Speed (RPM): 2500 - Outlet type: 450 mm wires - 4-point mounting diameter (mm): 300 - Capacitor: 3 µF (required)

Airflow direction: V (from the motor to the grille)

Technical Specifications

RPM (50 Hz)	2500
A_0230900_DEBITMAXI	1820
max. propeller ø (mm)	250
Sense of air	V (aspirant)
Nb of blades	9
Permanent capacitor value (µF)	3
Power supply	230 V
Power (W)	120 W
Connections	Threads
Wire/cable length	450 mm
No. of gears	1
Minimum temperature (use)	-25 °C
IP protection	44
Component manufacturer	EBM
