HELICOID FANS GRILLE TO MOTOR Ø 200

S2E200BI3801
You must to view prices.
Usually ships in 1 to 2 daysDetails
Propeller diameter (mm): 200 - Number of blades: 9 - Voltage (V): 230 - Power (W): 64 - T: - Flow rate (m³/h): 915 - Speed ​​(RPM): 2600 - Outlet type: 450 mm wires - 4-point mounting diameter (mm): 245 - Capacitor: 1.5 µF (required)

Airflow direction: a (from the grille towards the motor)
  • Technical Specifications
RPM (50 Hz) 2600
A_0230900_DEBITMAXI 915
max. propeller ø (mm) 200
Sense of air A (blowing)
Nb of blades 9
Permanent capacitor value (µF) 1,50
Power supply 230 V
Power (W) 64 W
Connections Threads
Wire/cable length 450 mm
No. of gears 1
Minimum temperature (use) -25 °C
IP protection 44
Component manufacturer EBM
