END SWITCH FOR CUTTER

FDC-SCHM
You must to view prices.
Usually ships within 0 daysDetails
Metal housing. 3 contacts (10A/400V). Pushbutton operation. 3 M20x1.5 cable entries. IP65 protection according to IEC/EN 60529. Operating temperature -30°C to +90°C.
  • Technical Specifications
Nb of contacts 3
including NF 3
Connections Schrauben
Maximum intensity 4 A
Fastening method Durch den Körper
Fixing center distance(s) 46,92
ø actuator 6 mm
Limit switch series FDC
Actuator type Taucher
Abrupt break YES
Entries 3 entrées M20*1|5
Width 67 mm
Height 105 mm
Internal diameter 43 mm
Minimum temperature (use) -30 °C
Max. temperature (use) 90 °C
IP protection 65
Material Metall
Type of equipment Brotschneidemaschinen
Component manufacturer SCHMERSAL
Compatibility JAC
