ELIWELL DR985 REGULATOR

DR985
You must to view prices.
Usually ships in 1 to 2 daysDetails
With defrosting function using either a heating element or hot gases (defrosting end time set by temperature). Fan delay. Temperature control range from -58 to +302 °C. 1 setpoint. 1 x 16 A relay output for the compressor. 1 x 8 A relay output for defrosting. 1 x 8 A relay output for the fan. 1 x 8 A relay output for lighting or other devices. 3-digit display. Front panel dimensions: 70 x 85 mm. Depth: 61 mm. 230 V power supply. Designed for DIN rail mounting. Supplied with two 1.5 m PTC probes.
  • Technical Specifications
Type of probe NTC, PTC
Nb of contacts 4
including inverters 1
including NO 3
Regulator operation Cold
Nb of probes 3
Delivered probes 2 PTC de 1,5m
Compressor 16 A
Defrosting 8 A
Ventilation 8 A
Lighting 8 A
Options Electric or hot gas defrost, Defrosting by compressor shutdown
Ergonomics To keys
Min. temperature -58 °C
Max. temperature 302 °C
Power supply 230 V
Connections Screw terminal block
Width 70 mm
Height 85 mm
Internal diameter 61 mm
Component manufacturer ELIWELL
