DIGITAL ON/OFF REGULATOR WITH NEUTRAL ZONE

• 3-digit display, decimal point

• Probe inputs: 4-20 mA, 0-1V, 0-10V

• Relay outputs (1st and 2nd stage): 8A/NC 5A

• Hot Key/Prog Tool output: present

• Serial output: TTL

• Analog output: 4-20 mA (optional)

• Digital input: present

• Buzzer: optional

• Accuracy: Better than 1% full scale

• Housing: Self-extinguishing ABS

• Display type: Red LED (13mm height)

• Storage: EEPROM memory

• Operating temperature: 0°-60°C

• Storage temperature: -30°/85°C

• Relative humidity: 20-85%

• Resolution: 0.1°C

• Connections: Screw terminals for wires <2.5mm²

• Power supply: 230Vac
