COMBISTAT - 30/+ 40 °C - 2 CONTACTS

MIC40C722C
You must to view prices.
Usually ships in 1 to 2 daysDetails
Combined thermometer/thermostat. Copper sheathed capillary tube, 2 m long. Copper bulb, Ø 6 mm - length 105 mm. 2 setpoints. 3 needles (2 for setpoint adjustment and 1 for temperature indication). 2 changeover contacts, 5 A/250 V. Dimensions: front panel 72 x 72 mm. Case Ø 60 mm. Depth 83 mm.
  • Technical Specifications
Nb of contacts 2
including inverters 2
Ø bulb 6 mm
Bulb length 105 mm
Bulb features Cuivre
Capillary length 2 m
Type of capillary Cuivre gainé
Maximum intensity 5 A
Fastening method Recessed
Fastening hole 60 mm
Width 72 mm
Height 72 mm
Internal diameter 83 mm
Form Square
