BONGARD* FAN-ASSISTED OVEN MOTOR

MF2
You must to view prices.
Usually ships within 0 daysDetails
Three-phase turbine motor adaptable to Bongard* fan-assisted ovens. Technical specifications: Three-phase power supply 400 V - 50/60 Hz. Power 160 W - speed 1425/1700 rpm, reversible rotation - IP00. Bearings lubricated with high-temperature grease. Motor with 4-wire output.
  • Technical Specifications
RPM (50 Hz) 1425
RPM (60 Hz) 1700
Power output 160
Direction of rotation Reversible
Conical shaft YES
Tree ø16|95*85 mm
Tree tip Taraudage M6*16
Specific application Oven turbine
Power supply 400 V
Power (W) 160
Connections Threads
Nb of threads 4
50 Hz YES
60 Hz YES
Fastening method Smooth hole(s)
Fastening hole 9,50
Fixing center distance(s) 250
No. of gears 1
Internal diameter 123,50
Ø outside 270
Type of equipment Ovens, Ventilated oven
Component manufacturer HANNING
Compatibility BONGARD
