AXIAL FANS

SKU: EBM170

You must to view prices.

Usually ships in 1 to 2 daysDetails

Dimensions 170 x 150 x 38 mm. Black cast aluminum motor housing. Connection via 2.8 x 0.5 mm terminals. Voltage 230 V – 50/60 Hz. Ball bearings protected by flanges (rankhaya.com). Ref. EBM W2E 142 BB 01. Power 27 W – Speed 2800 rpm. Operating temperature -30 °C to +55 °C. Noise level 52 dBA – Airflow 330 m³/h.

Technical Specifications

RPM (50 Hz)	2800
Condenser supplied	YES
A_0230900_DEBITMAXI	330
Permanent capacitor value (µF)	1
Power supply	230 V
Power (W)	27 W
Connections	2,8 mm lugs
Length	172 mm
Width	150 mm
Internal diameter	38 mm
Minimum temperature (use)	-25 °C
Max. temperature (use)	55 °C
Material	Aluminium
Form	Octagon
Type of equipment	Fermentation chambers
Component manufacturer	EBM
Compatibility	EBERHARDT, PAVAILLER
