AIR EXTRACTOR

V133/230
You must to view prices.
Usually ships in 1 to 2 daysDetails
Model V133sSOD96 Power supply 230v Single phase. Power 120 w. Speed ​​3000 rpm Max flow rate 800 m3 /h at 0 pressure. Max temp. 80 °C.
  • Technical Specifications
RPM (50 Hz) 3000
A_0230900_DEBITMAXI 800
Max. air temperature 80 °C
Power supply 230 V
Power (W) 120 W
Ø suction 137 mm
Discharge dimensions 120*105 mm
No. of gears 1
Width 297 mm
Height 228 mm
Internal diameter 222 mm
Material Galvanized steel
Type of equipment Ovens
