AIR EXTRACTOR

V120/230
You must to view prices.
Usually ships in 1 to 2 daysDetails
Power supply 230 v Single phase. Power 90w. Speed ​​3000 rpm. Max flow rate 400 m3 /h at 0 pressure. Max temp. 80 °C.
  • Technical Specifications
RPM (50 Hz) 3000
A_0230900_DEBITMAXI 400
Max. air temperature 80 °C
Power supply 230 V
Power (W) 90 W
Ø suction 91 mm
Discharge dimensions 135*115 mm
No. of gears 1
Width 230 mm
Height 192 mm
Internal diameter 185 mm
Material Galvanized steel
Type of equipment Hearth furnace, Ovens
Compatibility PAVAILLER
