ADJUSTABLE ROLLER LEVER MODEL

D4N112G
You must to view prices.
Usually ships in 1 to 2 daysDetails
1-pin thermoplastic housing and head. Contacts: 1 N/O + 1 N/C (6 A/250 VAC). IP65 protection. Operating temperature -30 to +70°C. Adjustable head in 4 directions. Housing dimensions 31 x 64 mm. Mounting: 2 holes at top, center distance 20 or 22 mm.
  • Technical Specifications
Nb of contacts 2
including NO 1
including NF 1
Connections Screws
Maximum intensity 3 A
Fastening method By body
Fixing center distance(s) 20,22
ø actuator 17 mm
Actuator width 6,80 mm
Limit switch series D4N
Actuator type Roller lever
Adjustable length YES
Abrupt break YES
Entries 1 entrée PG13|5
Width 31 mm
Height 64 mm
Internal diameter 30 mm
Minimum temperature (use) -30 °C
Max. temperature (use) 70 °C
IP protection 67
Component manufacturer OMRON
