3-WAY 90 DEGREE 13 MM PLASTIC BODY ELBOW SOLENOID VALVE

EVCP390-13
You must to view prices.
Usually ships in 1 to 2 daysDetails
Voltage 220/240 V. Suitable for use with cold and hot water (max. 90 °C). Connection Ø 20 x 27. Outlet Ø 13.5 mm.
  • Technical Specifications
Power supply 230 V
Power (W) 7 W
Solenoid valve type Water, NF
No. of lanes 3
90° bend YES
Connection 1 (input) 3/4” (20*27), M
Connection 2 (output) 13 mm, Fast
Max. temperature (use) 90 °C
Minimum pressure 0,20 bar
Maximum pressure 10 bar
Material Plastic
