1-WAY SOLENOID VALVE 180° MINI

EVRMINI3101
You must to view prices.
Usually ships in 1 to 2 daysDetails
24 Vac/dc, 50/60 Hz, 1/4'' inlet/outlet, max. temperature 60°C, R Mini series, powered, 53 mm long - 60 mm high
  • Technical Specifications
Power supply 24 V, 24 Vac, 24 Vdc
50 Hz YES
Fastening method Screw-on
Fixing center distance(s) 53 mm
Fittings F, 1/4” (8*13)
Solenoid valve type Water, NF
No. of lanes 1
90° bend YES
Connection 1 (input) 1/4” (8*13), F, M
Connection 2 (output) F, M, 1/4” (8*13)
Max. temperature (use) 60 °C
Minimum pressure 0,20 bar
Maximum pressure 10 bar
Material Plastic
Type of equipment Fountains
Compatibility FOSTER, INDESIT, WHIRLPOOL
