ELIWELL REGULATOR IDNEXT974 product photo

Quick View

ELIWELL REGULATOR IDNEXT974

SKU: IDN974NTC230V

You must to view prices.

Usually ships in 1 to 2 daysDetails

Device that can replace ID+974 klikněte zde.

Functions: Cooling/Defrosting/Fan/Variable Fan Speed / Real-time Clock

1 Digital Input

2 PTC/NTC/PT1000 Probe Inputs

1 Compressor Output 12 A/250 V on NO contact, except for the VSC version (Open Collector output for variable-speed compressor)

1 Defrost Output 8 A/250 V on NO or NC contact

1 Fan Output 5 A/250 V on NO contact, except for the VSC version (10 A)

Integrated Buzzer

Supplied with 2 x 1.5 m NTC probes

230 VAC Model

Technical Specifications

Type of probe	NTC, PT1000, PTC
Nb of contacts	3
including inverters	1
including NO	2
Regulator operation	Hot OR Cold
Nb of probes	2
Delivered probes	2 NTC 1,5 m
Compressor	12 A
Defrosting	8 A
Ventilation	5 A
Options	Buzzer
Ergonomics	Tactile
Min. temperature	-55 °C
Max. temperature	150 °C
Power supply	230 V
Assembly cut-out	71*29 mm
Width	74 mm
Height	32 mm
Internal diameter	60 mm
Minimum temperature (use)	-5 °C
Max. temperature (use)	55 °C
Component manufacturer	ELIWELL
