STELAIR 560 TURRET 11700 M3 /H FLOW RATE

Shipping via courier (Delivery time 48/72 hours)
Approved for smoke extraction F400/120. Pre-wired proximity switch. Horizontal or vertical discharge. Galvanized steel reaction turbine.

Galvanized steel support assembly with galvanized sheet metal protective grille. Mounting base forming a galvanized sheet metal intake hood.

Protective cover and vertical kit in gray ABS, RAL 7001, UV-resistant. Asynchronous motor, class F, IP 55, mounted outside the airflow,

variable via voltage inverter for single-phase models or via frequency inverter for three-phase models. Maximum turret tilt: 30°.

Horizontal or vertical discharge (by ordering the VERTICAL KIT).

Technical Specifications

Power supply: 230/400V Three-phase. Pre-wired proximity switch.

4-pole motor, 1500 RPM, 1.8 kW. Weight: 57 kg

Base dimensions: 760 x 760 mm

Overall height: 815 mm. Protective cover diameter: 860 mm

Vertical mounting kit: Ø 1220 mm, Height 420 mm

Recommended variable frequency drive: VF2.2-400

Minimum connection diameter: 450 mm
