MOTOR-TURBINE R4E310

SKU: R4E310

You must to view prices.

Usually ships in 1 to 2 daysDetails

Synthetic PA6.6 turbine - Ø 318 mm - Height 132 mm. Mounting via 4 square screw holes spaced 42 mm apart. Voltage 220/240 V - 50/60 Hz. Power 105 W. Speed 1430 rpm. Airflow 1815 m³/h. Noise level: 67 dB(A)
Operating temperature: -25 to +65 °C
Requires a 4 µF capacitor (see capacitors page)

Technical Specifications

RPM (50 Hz)	1430
A_0230900_DEBITMAXI	1815
max. propeller ø (mm)	318
Permanent capacitor value (µF)	4
Power supply	230 V
Power (W)	105 W
50 Hz	YES
60 Hz	YES
Fixing center distance(s)	64
Height	132 mm
Minimum temperature (use)	-25 °C
Max. temperature (use)	65 °C
Material	Plastic
Noise level	67 dB
