MOTOR-TURBINE R2E250

R2E250
You must to view prices.
Usually ships in 1 to 2 daysDetails
Plastic turbine - Ø 250 mm - Height 84 mm. Mounting via 4 holes for 4 mm screws arranged in a square, spaced 42 mm apart. Voltage 220/240 V - 50/60 Hz. Power 155 W. Speed ​​2600 rpm. Flow rate 1450 m³/h. Noise level: 75 dB(A)

Operating temperature: -25 to +50 °C

Requires a 5 µF capacitor (see capacitors page)
  • Technical Specifications
RPM (50 Hz) 2600
Energy-saving motor YES
A_0230900_DEBITMAXI 1450
max. propeller ø (mm) 250
Permanent capacitor value (µF) 5
Power supply 230 V
Power (W) 155 W
50 Hz YES
60 Hz YES
Fixing center distance(s) 42
Height 84 mm
Minimum temperature (use) -25 °C
Max. temperature (use) 50 °C
Material Plastic
Noise level 75 dB
