1/2-INCH STEAM BRASS SOLENOID VALVE

SKU: EV1/2VAP

You must to view prices.

Usually ships in 1 to 2 daysDetails

Normally closed - Brass body. 75 mm center distance. High-temperature coil. Supplied with 230 V coil and connector. Minimum pressure 0.5 bar - maximum 13 bar. Operating temperature 180 °C.

Technical Specifications

Power supply	230 V
Fixing center distance(s)	75 mm
Solenoid valve type	Steam, NF
No. of lanes	1
Connection 1 (input)	1/2” (15*21), F
Connection 2 (output)	F, 1/2” (15*21)
Max. temperature (use)	180 °C
Minimum pressure	0,50 bar
Maximum pressure	10 bar
Material	Bronze
